24FT Commercial-Grade Big Ceiling Fans Optimal Air Circulation
1. High Torque Density
2. Wider blades
3. Cost saving and energy consumption reduction
4. Precise Speed Control
5. Durability & Safety
DIAMETER | 8ft(2.5m) | 12ft(3.8m) | 16ft(5.0m) | 20ft(6.2m) | 24ft(7.3m) |
MODEL | SFFCA25 | SFFCA38 | SFFCA50 | SFFCA62 | SFFCA73 |
AIR VOLUME | 6500m³/min | 8600m³/min | 13050m³/min | 14100m³/min | 15850m³/min |
MAXIMUM SPEED | 140RPM | 100RPM | 70RPM | 60RPM | 55RPM |
WEIGHT | 35Kg | 51Kg | 75Kg | 90Kg | 127Kg |
MOTOR POWER | 0.3kw | 0.4kw | 1.1kw | 1.1kw | 1.5kw |
FULL LOAD CURRENT | 1.8AMPS/220V | 2.0Amps/380v 2.3Amps/220v | 2.4Amps/380v 3.2Amps/220v | 3.0Amps/380v 3.5Amps/220v | 3.5Amps/380v 5.5Amps/220v |
Basic technical parameters: Model SFFCA73 (PMSM SERIES)
| No. | Main Configuration | Description | Photo |
| 1 | Motor | 1. Industry's top PMSM motor; Power: 1.5kw; Insulation class: F, 50/60HZ; 2. Energy efficiency rating IE2; Operating noise less than 40dB; 3. No gear box, no oil change, truly maintenance-free; |
|
| 2 | Electrical control system | Built-in safety protection module, Control system: Built-in safety protection module, automatically cut off the output in the event of an accident. |
|
| 3 | Blades | Our blade is made of 6063T5 special high-strength aviation magnesium-aluminum alloy material, which is extruded into one piece. |
|
Applications:
✔ Manufacturing
✔ Industrial Plants
✔ Warehousing & Logistics
✔ Construction & Mining
BIGFANS have own installation service team exceeded 100 people, covering the four major regions of South China, East China, Southwest China and Northeast China, providing 24-hour service.
The company's after-sales department adopts an 8-hour response and a 24-hour problem-solving mechanism to serve you wholeheartedly.
Each fan is securely wrapped and placed in a sturdy wooden box with ample cushioning material to prevent any damage during transit, and a set of big fans is composed of a square box and a long box.
Q: Are you factory or trading company?
A: We are factory which established more than 12 years.
Q: How is your motor’s quality compared with others?
A: High efficiency (85%~89%) is our strength.
Low repair rate (less than 0.08%).
All the motors have passed ISO9000, CE.
|
|
